Excavator-mounted magnet is a powerful attachment that turns any standard excavator into a highly efficient scrap metal recovery machine. Designed to lift, separate, and move ferrous materials with ease, this device is widely used in demolition sites, recycling yards, and steel mills. The magnet attaches directly to the excavator, using the machine’s hydraulic or electric system to generate a strong magnetic field. Whether you need to clean up construction debris or sort shredded steel, an excavator-mounted magnet saves time, labor, and fuel. Models like the YG5 series offer a range of sizes and power ratings, from smaller units handling 300 kg loads to larger ones capable of lifting up to 4 tons. With duty cycles rated at 75%, these magnets are built for continuous, demanding work.
Excavator Mounted Magnet Parameters
| Model | Current/Voltage | Power/KW Current (A) | Dimensions | Duty Cycle | Weight | Feeding Parameters/Reinforcement Bar Ends |
| YG5-70L | 30/220 | 3KW 15A | 70/260/300 | 75% | 0.5T | 300 kg |
| YG5-80L | 30/220 | 4KW 18A | 80/260/300 | 75% | 0.7T | 400 kg |
| YG5-90L | 40/220 | 6KW 26.6A | 90/260/300 | 75% | 0.9T | 500 kg |
| YG5-100L | 40/220 | 7KW 30.6A | 100/260/300 | 75% | 1T | 600 kg |
| YG5-110L | 40/220 | 8KW 35A | 110/260/300 | 75% | 1.2T | 800 kg |
| YG5-120L | 50/220 | 10KW 41A | 120/260/300 | 75% | 1.3T | 1 T |
| YG5-130L | 50/220 | 12kw 45A | 130/260/300 | 75% | 1.6T | 1.2 T |
| YG5-150L | 60/220 | 15kw 72A | 150/300/340 | 75% | 2.2T | 1.7 T |
| YG5-165L | 60/220 | 16kw 75A | 165/300/340 | 75% | 2.8T | 2.3 T |
| YG5-180L | 90/220 | 22kw 102A | 180/320/370 | 75% | 3.3T | 3 T |
| YG5-210L | 130/220 | 28kw 162A | 210/320/370 | 75% | 4T | 4 T |
Excavator Scrap Magnets Deliver Heavy Material Lifting Power
Excavator mounted magner brings impressive features that make daily scrap handling simple and efficient. First, it features a heavy-duty steel shell that protects the internal electromagnetic coils from rough impacts during operation. To suit different machinery sizes, models range in weight from 0.5T to 4T, with power options from 3KW up to 28KW. A standard 75% duty cycle ensures continuous working capacity throughout long shifts without overheating issues. The electrical power system operates on a stable 220V setup, utilizing current inputs ranging from 15A up to 162A depending on the model capacity. Furthermore, these magnets feature weatherproof sealing, keeping moisture and dust away from sensitive components. Easy hydraulic and electrical hookups allow operators to attach or detach the unit quickly without long downtime.
How Does an Excavator Magnet Lift Heavy Steel Equipment?
Understanding the inner working principles of an excavator mounted magnet is simple. Inside the heavy metal casing, copper or aluminum wires are wrapped around a central magnetic iron core. When the excavator operator turns on the electric switch inside the cab, electric current flows through these coils. This continuous electric current generates a strong magnetic field around the bottom steel plate. The magnetic field exerts an intense pull on any iron, steel, or magnetic scrap metal nearby. When the machine moves the scrap to the desired location, the operator cuts off the electric supply. The magnetic field collapses instantly, dropping the heavy scrap safely onto the pile.
Industrial Applications for Metal Scrap Removal
Discover how an excavator mounted magnet transforms daily operations across various industrial applications:
- Demolition Site Cleanup: Rapidly clears iron rebar, wire meshes, and scrap steel pieces from broken concrete debris.
- Scrap Metal Recycling Yards: Efficiently sorts, gathers, and loads loose scrap metal into transport trucks or sorting bins.
- Railway Maintenance: Lifts and shifts steel tracks, heavy metal plates, and loose iron spikes during rail repair jobs.
- Building Construction Sites: Keeps busy work areas free of dangerous sharp nails, loose metal scraps, and stray steel pieces.
- Foundry Waste Processing: Sorts through slag and waste piles to recover valuable leftover iron and steel materials.
Advantages of Using an Excavator Mounted Magnet
Investing in a high-quality excavator mounted magnet offers massive advantages for busy job sites.
- First, it greatly improves worker safety by reducing the need for workers to handle sharp or heavy metal scrap manually.
- Second, it reduces operational costs by cutting down job completion times and lowering fuel usage per ton of handled material.
- Third, the strong magnetic hold prevents dropped materials, protecting equipment tires and hydraulic lines from unexpected punctures.
- Additionally, these magnets fit a wide range of excavator brands. The solid internal insulation extends overall service life.
By choosing this tool, businesses increase daily profits and ensure cleaner, safer working conditions.
Why Choose Our Company for Machinery Attachments?
When you select our industrial machinery tools, you are choosing guaranteed quality and dedicated technical support. We use top-grade raw materials and precise manufacturing techniques to build long-lasting equipment. Every product undergoes strict factory testing for magnetic strength, electrical stability, and structural durability before shipment. Our expert engineering team provides clear installation guidance and responsive customer service to keep your operations running smoothly. We also offer customized options to match your specific excavator model and job site demands. Partnering with us means getting reliable performance, quick product delivery, and dedicated aftermarket support for all your project needs.
Explore More Attachments – Contact Us for Personalized Recommendations
Besides the excavator mounted magnet, we also offer hydraulic grapples, demolition shears, pulverizers, and auger drives – all designed to maximize your excavator’s versatility. If you are handling scrap metal, our magnet is the perfect start, but pairing it with a sorting grapple can double your efficiency. To build a fully efficient job site fleet, consider combining your excavator mounted magnet with our other heavy attachments, such as hydraulic rock breakers, hydraulic shear attachments, and heavy-duty screening buckets. Using the right combination of tools maximizes your excavator’s versatility and productivity. If you want to learn more about customized configurations, our specialist team is ready to assist you. Contact us today via email or inquiry form to receive a detailed quote and expert guidance tailored to your project requirements.
